Product Overview

The Magnetic Drum Separator is a highly efficient iron removal device that integrates conveying and magnetic separation functions. Its core component is a drum housing either a permanent magnetic assembly or an electromagnetic coil system. This magnetic core/coil generates a strong magnetic field, magnetizing the drum's surface. As material is conveyed over the drum on a belt, ferrous contaminants are attracted and held onto the rotating drum surface. These impurities are carried by the drum's rotation to the area of weak or zero magnetic field (typically the bottom or side), where they are released by gravity or a scraper into a collection chute. The cleaned material continues its journey on the belt, completing the separation process. Widely used in mining, coal, construction materials, grain processing, and other industries, this equipment is essential for protecting downstream machinery and enhancing product quality.

Product Advantages

Integrated Design: Combines conveying and magnetic separation in one unit, eliminating the need for separate equipment. This saves valuable installation space and reduces capital investment. Its compact structure allows it to directly replace standard conveyor pulleys for easy and quick installation.

Continuous and Efficient Operation: Operates synchronously with the conveyor belt for non-stop iron removal. It features a large magnetic field coverage area, capable of handling both large tramp iron and fine ferrous contaminants simultaneously. With a high separation efficiency often exceeding 99%, it ensures material purity.

Low Maintenance and Operating Cost: Permanent magnet models require no electrical power and consume zero energy, needing only periodic inspection of the drum wear surface and scrapers. Electromagnetic models offer adjustable magnetic field strength for greater versatility. The equipment boasts stable and reliable operation with long maintenance intervals, resulting in low total cost of ownership.

High Durability: The drum shell is protected by wear-resistant and anti-corrosion coatings, making it suitable for harsh, dusty environments like mines and construction sites, thereby extending the equipment's service life. Critical components are manufactured from high-quality materials for excellent impact and wear resistance.

High Adaptability and Flexibility: Can be matched with conveyor belts of various widths and speeds. Parameters such as magnetic field strength and drum diameter can be customized based on material characteristics and processing capacity requirements to meet diverse application needs.

Product Parameters

Application Scenarios

Mining and Aggregates Industry: Used for removing iron from conveyed raw materials like ores, quartz sand, and limestone to protect crushers and grinding mills from damage by metal contaminants. Effectively removes tramp iron and ferrous debris, extending equipment lifespan.

Coal Industry: Installed at the head or tail pulley of raw coal conveyor belts to remove tramp metal (e.g., bolts, tools, bars) from coal, safeguarding conveying and sorting equipment. Prevents ferrous objects from entering crushers, screens, etc., avoiding jams or damage.

Recycling and Resource Recovery: Separates ferrous metals from industrial waste and municipal solid waste streams, enabling the recovery and reuse of scrap steel and iron. Improves resource recovery rates and reduces environmental pollution.

Construction Materials Industry: Removes iron from materials like cement clinker, gypsum, and ceramic raw materials, improving finished product purity and reducing defects. Ensures product quality and enhances value.

Grain Processing: Cleans grains and animal feed during conveying by removing foreign ferrous objects like nails and wire fragments. Prevents equipment clogging or damage and ensures food safety.

Selection Guide

Permanent Magnet Drum: Suitable for applications with lower ferrous contamination levels and where adjustable field strength is not critical. Advantages include zero energy consumption, simple maintenance, and low operating costs. Especially well-suited for harsh, dusty environments like mines and construction sites.

Electromagnetic Drum: Suitable for applications with higher ferrous contamination levels or where adjustable magnetic field strength is required. Offers a wide adjustment range and excellent separation performance. Requires electrical power supply and involves slightly more complex maintenance. Ideal for applications demanding high separation efficiency.

Key Selection Points: The appropriate model should be selected based on material characteristics (particle size, moisture content, ferrous contamination level), processing capacity, and conveyor belt parameters (width, speed). It is recommended to provide detailed operational parameters for professional technical assistance in model selection.

Installation and Maintenance

Installation Requirements: The unit should be installed at the conveyor head or at a point where material is evenly distributed on the drum surface. Foundation dimensions should be checked before installation to ensure the unit is mounted levelly. Electrical wiring must comply with relevant codes, with proper grounding installed.

Routine Maintenance: Periodically inspect the drum shell for wear and replace severely worn scrapers promptly. Check bearing lubrication and apply grease regularly. Inspect electrical connections for tightness and insulation integrity.

Important Notes: Personnel must keep clear of the equipment during operation to prevent accidents. Before performing maintenance, the power must be disconnected and warning signs posted. Regularly clean accumulated material around the equipment to maintain cleanliness.
