Self-Cleaning Magnetic Rod Separator with 8000-15000GS Magnetic Field Strength, 3000GS/cm Gradient & Adjustable Self-Cleaning Cycle

Brand Name:	TMY
Model Number:	31
MOQ:	10
Payment Terms:	T/T
Supply Ability:	IN STOCK

Detail Information

Product Description

Detail Information

Place of Origin:

TIANJIN,CHINA

Certification:

ISO9001

Magnetic Rod Quantity:

Customizable

Magnetic Rod Length:

Customizable

Magnetic Field Strength:

8000-15000GS

Magnetic Gradient:

Up To 3000GS/cm

Magnetic Field Type:

Permanent Magnet

Processing Capacity:

Powder: 0.5-30T/h, Liquid: 1-50m³/h

Flow Velocity:

Powder: 0.1-0.8m/s, Liquid: 0.2-1.5m/s

Applicable Particle Size:

0.01-10mm

Cleaning Cycle:

Adjustable

Cleaning Method:

Self-Cleaning

Product Type:

Permanent Magnetic Rod Separator / Self-Cleaning Iron Remover

Company Profile:

High-tech Enterprise Integrating R&D, Production, Sales And Service Of Magnetic Application Equipment

Highlight:

Self-cleaning magnetic rod separator

Permanent magnetic separator 8000-15000GS

Magnetic rod separator high gradient

Product Description

Customizable Permanent Magnetic Rod Separator | Auto Self-Cleaning Without Manual Operation & 8000-15000GS Strong Magnet For High Efficient Iron Removal

2. Core Selling Paragraph

This self-cleaning permanent magnetic rod separator adopts permanent magnet field design with magnetic field strength 8000-15000GS and maximum magnetic gradient up to 3000GS/cm for powerful iron impurity capture. It handles both powder and liquid materials: powder processing capacity 0.5-30T/h, liquid flow rate 1-50m³/h, suitable for raw materials with particle size 0.01-10mm. The quantity and length of magnetic rods can be customized freely, matching powder flow velocity 0.1-0.8m/s and liquid flow velocity 0.2-1.5m/s for various production lines. Equipped with automatic self-cleaning structure with adjustable cleaning cycle, no manual shutdown for iron removal to guarantee continuous production. Widely used in food, chemical, building material, lithium battery raw material, pharmaceutical powder industries for iron removal and purification, all parameters support customized bulk export for overseas trade.

3. Product Specifications

Item	Specification
Magnetic Rod Quantity	Customizable
Magnetic Rod Length	Customizable
Magnetic Field Strength	8000-15000GS
Magnetic Gradient	Up to 3000GS/cm
Magnetic Field Type	Permanent Magnet
Processing Capacity	Powder: 0.5-30T/h, Liquid: 1-50m³/h
Flow Velocity	Powder: 0.1-0.8m/s, Liquid: 0.2-1.5m/s
Applicable Particle Size	0.01-10mm
Cleaning Cycle	Adjustable
Cleaning Method	Self-Cleaning
Product Type	Permanent Magnetic Rod Separator / Self-Cleaning Iron Remover
Company Profile	High-tech enterprise integrating R&D, production, sales and service of magnetic application equipment
Application Industries	Lithium battery powder, food processing, chemical raw material, pharmaceutical powder, plastic pellet, construction sand, ceramic slurry iron removal & purification

4. Product Introduction

We are a high-tech enterprise integrating independent R&D, manufacturing, global sales and after-sales service for all kinds of magnetic application equipment. This self-cleaning permanent magnetic rod separator is a universal core iron removal machine for powder and liquid materials. It adopts high-performance permanent magnetic rods to generate stable strong magnetic field without extra excitation power supply, saving power consumption for long-term operation.

The magnetic field strength ranges from 8000GS to 15000GS, with maximum magnetic gradient reaching 3000GS/cm. It can efficiently capture tiny iron scraps, rust and magnetic impurities, preventing raw material contamination from scratching downstream equipment and degrading finished product purity. This machine supports two material working conditions: powder processing capacity 0.5-30 tons per hour, liquid processing flow 1-50 cubic meters per hour. Matching flow velocity: 0.1-0.8m/s for powder, 0.2-1.5m/s for liquid, covering small, medium and large production line capacity demands.

5. FAQ

Q1: What is the magnetic field strength and maximum magnetic gradient of this magnetic rod separator?

A1: Magnetic field strength: 8000-15000GS, maximum magnetic gradient up to 3000GS/cm.

Q2: Can we customize the quantity and length of magnetic rods?

A2: Both magnetic rod quantity and length are customizable as required.

Q3: What are the processing capacity and matching flow velocity for powder and liquid respectively?

A3: Powder capacity: 0.5-30T/h, powder flow velocity:0.1-0.8m/s; Liquid capacity:1-50m³/h, liquid flow velocity:0.2-1.5m/s.

Q4: What particle size range of materials can this machine handle? What is its cleaning mode?

A4: Applicable particle size:0.01-10mm; Full automatic self-cleaning mode with adjustable cleaning cycle.

Q5: What type of magnetic field does this machine use? What is your company’s business scope?

A5: Permanent magnet magnetic field; We are a high-tech enterprise engaged in integrated R&D, production, sales and service of magnetic application equipment.
